EMT JSD Novel Titan Phono Cartridge
All EMT Novel products are equipped with the innovative EMT multi-layer core transducer with titanium/sapphire cantilever. Incredible realistic performance is achieved, while at the same time the tried and trusted EMT typical specs are respected.
The JSD Novel Titan features a titanium body and pure silver coil for genuine and balanced audio experience. The matt surface is diamond plated.
All EMT Novel products are equipped with the innovative EMT multi-layer core transducer with titanium/sapphire cantilever. Incredible realistic performance is achieved, while at the same time the tried and trusted EMT typical specs are respected.
The JSD Novel Titan features a titanium body and pure silver coil for genuine and balanced audio experience. The matt surface is diamond plated.
All EMT Novel products are equipped with the innovative EMT multi-layer core transducer with titanium/sapphire cantilever. Incredible realistic performance is achieved, while at the same time the tried and trusted EMT typical specs are respected.
The JSD Novel Titan features a titanium body and pure silver coil for genuine and balanced audio experience. The matt surface is diamond plated.
-
Diamond: MR HP
Cantilever: Titanium / Sapphire
Transducer: EMT multi-layer core technology
Coil: Pure Silver
Connection: 1/2" – 4pin
Vertical Tracking Angle: 23°
Weight: 16g
Tracking force: 2,1g
Output voltage: 1mV @ 5cm/s
Compliance: 12µm/mN
Frequency response: 20 - 30‘000Hz
Impedance: 2x 16Ω
Recommended load: 100 - 200Ω
-
