Digital, Done Right
The CD3.1x/II is the first model of integrated CD player in our range to feature the highly regarded Analogue Devices AD1865 digital to analogue converter chip, the same device that we use in our more costly stand alone DACs. This 18bit device has consistently outperformed every competing chip we have tested regardless of specification or price.
Dedicated Red Book Transport
The transport is our now classic in house modified Philips CD mechanism, designed purely to read true Red Book CD, which in our opinion is still the best possible Digital music format currently available.
The analogue output stage features two ECC88 dual triode valves and our own custom designed and manufactured Audio Note (UK) copper foil capacitors. Our own Tantalum resistors are also used in critical areas, offering a quite remarkable level of performance.
-
Optical Pick-Up: 3 beam laser
Semi-Conductor Laser: 780nm
Output Impedance: Less than 2 KOhm
Reference Output: 3.0V RMS (approx.)
Channel Balance: Less than 0.5dB
Valve Complement: 2 x ECC88
Unit Weight: 8 kg
Unit Dimensions: 142mm (h) x 445mm (w) x 420mm (d)
Mains Input: AC 100-120V / 220-240V 50/60Hz
Max. Power Consumption: 48W
Finishes: Fascia - Anodised Aluminium / Black Acrylic / White Acrylic
Due to Audio Note (UK)'s ongoing research and development program, specifications are subject to change without notice.
