The Aurorasound VIDA Supreme Phono Stage is the reference phono preamplifier from the Japanese manufacturer Aurorasound, developed by designer Shinobu Karaki. It is built around an LCR-type equalization network, a topology valued in high-end analog reproduction for its precise RIAA accuracy and low distortion. The circuit uses discrete transistor and FET amplifier modules, while the RIAA network employs a custom choke transformer developed with Lundahl Transformers. The design also separates the power supply in a dedicated external chassis to reduce electrical noise and improve stability.
The VIDA Supreme is designed to accommodate a wide range of cartridges and systems. It supports both MM and MC cartridges with selectable gain and loading, and offers balanced and unbalanced connections for integration with modern high-end systems. Modular plug-in cards allow additional cartridge matching or specialized functions, while practical features such as stereo/mono switching, cartridge demagnetization, a subsonic filter and protective auto-muting make it adaptable for serious vinyl playback. Measured performance includes very low distortion (around 0.008%) and accurate RIAA equalization within ±0.25 dB.
LCR Type Phono Stage Amplifier
Good resolution and low distortion in low frequency range, rich and massive middle, stable and delicate High.
Useful functions for modern analog audio play back.
Large size MUTE switch, Gain select, Stereo./Mono, Subsonic filter, Cartridge Degauss.Complete L/R independent design and construction for very good channel separation and 3D sound stage.
Plug-In modules for matching with various kind of cartridges.
[Standard Equipped] : MM and MC low impedance under 14ohm, RCA and XLR balanced input
[Option] : Two slotsDeveloped new amplifier module using made in Japan discrete transistors and FETs.
High gain, low distortion, low noise, high drivabilitySpecial customized RIAA filter choke transformer, Lundahl (same with VIDA）
Made in Japan audio grade oxide film registers, 1% error rate.
Made in Japan audio grade Electrolytic capacitors, very stable and long life.
High quality Polypropylene film capacitors, made in Germany.
Use made in Japan high reliability relay switch for all signal path switching.
Shaving solid RCA jacks with rhodium plating. Neutrk made XLR connectors.
Very ridged and heavy , all solid aluminum chassis to firmly supporting circuit boards.
Carbone compositional foot insulators.
External Power Supply Unit for eliminating noise influence of power transformer.
Large size, large capacity Medical grade Troidal Transformer, L/R independent.
New design power cable, Coaxial inverse winding OFC, Better sound resolution and clarity.
-
Input: MM, Gain 40dB, Load Impedance select 47kΩ/14kΩ 100pF/0/330pF — MC, Gain 62.5dB, For cartridge Impedance under 14Ω — Plug-In option 2 slots
Output: Line level signal, RCA un-balance and XLR Balance (1/GND, 2/Hot, 3/Cold)
Output Impedance: RCA 47Ω,XLR Balance 47Ω
RIAA deviation: 10Hz -20kHz +/- 0.25dB
Input Noise: MC 144dBV, MM 126dBV
THD+N: MC 0.008%, MM 0.008%
Functions : Gain select +8db at High position — Subsonic Filter -12dB/oct. 20Hz — Cartridge Degauss, Passive type — Stereo/Monaural mixing L/R signals and canceling vertical vibration — MUTE Useful muting at cartridge up/down — Auto-Muting, In the case of big hot plug noise or external shock noise, Automatic muting will enable in order to protect Speakers and Amplifiers
Size: Main unit W420 x D350 xH106mm — PSU: W270 xD154 xH85mm
Weight: Main unit 9.2kg — PSU 3.2kg
Power consumption: AC120V for USA, AV220V~ AC240V Asia and Europe, 50/60Hz 60W
PSU cable: 95cm x2 units
