Kuzma 4Point 9 Tonearm
4Point 9 is a shorter version of the 4Point tonearm. Due to its 9-inch length and the absence of a VTA tower, this tonearm is lighter and more compact, making it suitable for most suspended turntables.
All 4P9 tonearms have been fitted with sapphire/ruby cup bearings since their introduction, and all 4P11 and 4P14 models since July 1st, 2018.
4Point 9 is a shorter version of the 4Point tonearm. Due to its 9-inch length and the absence of a VTA tower, this tonearm is lighter and more compact, making it suitable for most suspended turntables.
All 4P9 tonearms have been fitted with sapphire/ruby cup bearings since their introduction, and all 4P11 and 4P14 models since July 1st, 2018.
4Point 9 is a shorter version of the 4Point tonearm. Due to its 9-inch length and the absence of a VTA tower, this tonearm is lighter and more compact, making it suitable for most suspended turntables.
All 4P9 tonearms have been fitted with sapphire/ruby cup bearings since their introduction, and all 4P11 and 4P14 models since July 1st, 2018.
-
Effective lenght: 229 mm
Arm mount distance: 212 mm
Spindle to pivot distance: 212 mm
Bearing type: 4 points (sapphire-transparent / ruby-red cups / steel pivots-see modification note for 4P11 or 4P14)
Effective mass: 13 g
Total mass: 920 g
Offset angle: 23 deg
VTA adjustment: Yes
Azimuth: Worm drive
Tube: Conical
Bias: Yes
Max cartridge mass: 35 g
Damping: No
Detachable headshell: Yes ( three dots)
Arm mount: Kuzma
Standard wiring: Silver
Accessories: Yes
Optional wiring: Yes
Optional connectors: XLR,5 Pin
